| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Jetta |
| Generation | Jetta V |
| Type (Engine) | 1.6 TDI (105 Hp) |
| Start of production | 2009 year |
| End of production | 2010 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 5.8 l/100 km 40.6 US mpg 48.7 UK mpg 17.2 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 4.1 l/100 km 57.4 US mpg 68.9 UK mpg 24.4 km/l |
| Fuel consumption (economy) – combined (NEDC) | 4.7 l/100 km 50 US mpg 60.1 UK mpg 21.3 km/l |
| CO2 emissions (NEDC) | 122 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 12 sec |
| Acceleration 0 – 62 mph | 12 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 11.4 sec |
| Maximum speed | 187 km/h 116.2 mph |
| Emission standard | Euro 4 |
| Weight-to-power ratio | 12.9 kg/Hp, 77.4 Hp/tonne |
| Weight-to-torque ratio | 5.4 kg/Nm, 184.2 Nm/tonne |
| Engine specs | |
| Power | 105 Hp @ 4400 rpm. |
| Power per litre | 65.7 Hp/l |
| Torque | 250 Nm @ 1500-2500 rpm. 184.39 lb.-ft. @ 1500-2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | CAYC |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 79.5 mm 3.13 in. |
| Piston Stroke | 80.5 mm 3.17 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1357 kg 2991.67 lbs. |
| Max. weight | 1940 kg 4276.97 lbs. |
| Max load | 583 kg 1285.29 lbs. |
| Trunk (boot) space – minimum | 527 l 18.61 cu. ft. |
| Fuel tank capacity | 55 l 14.53 US gal | 12.1 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (8%) | 1700 kg 3747.86 lbs. |
| Permitted trailer load with brakes (12%) | 1400 kg 3086.47 lbs. |
| Permitted trailer load without brakes | 710 kg 1565.28 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4554 mm 179.29 in. |
| Width | 1781 mm 70.12 in. |
| Width including mirrors | 2010 mm 79.13 in. |
| Height | 1459 mm 57.44 in. |
| Wheelbase | 2578 mm 101.5 in. |
| Front track | 1534 mm 60.39 in. |
| Rear (Back) track | 1512 mm 59.53 in. |
| Minimum turning circle (turning diameter) | 10.9 m 35.76 ft. |
| Approach angle | 14.6° |
| Departure angle | 12.4° |
| Ramp-over (brakeover) angle | 9.9° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Coil spring, Wishbone, Transverse stabilizer |
| Rear suspension | Independent multi-link suspension, Transverse stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/55 R16 |
| Wheel rims size | 6.5J x 16 |
| What is the body type, Volkswagen Jetta V? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Volkswagen Jetta V 1.6 TDI (105 Hp)? | 4.7 l/100 km 50 US mpg 60.1 UK mpg 21.3 km/l |
| How ECO is the car, Volkswagen Jetta 1.6 TDI (105 Hp)? | 122 g/km CO2 Euro 4 |
| How fast is the car, 2009 Jetta V 1.6 TDI (105 Hp)? | 187 km/h | 116.2 mph 0-100 km/h: 12 sec 0-60 mph: 11.4 sec |
| How much power, Volkswagen Jetta Sedan 2009 1.6 TDI (105 Hp)? | 105 Hp, 250 Nm 184.39 lb.-ft. |
| What is the engine size, Volkswagen Jetta Sedan 2009 1.6 TDI (105 Hp)? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2009 Volkswagen 1.6 TDI (105 Hp)? | 4, Inline |
| What is the drivetrain, Volkswagen Jetta V Sedan 2009 1.6 TDI (105 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2009 Volkswagen Jetta Sedan? | 4554 mm 179.29 in. |
| How wide is the vehicle, 2009 Volkswagen Jetta Sedan? | 1781 mm 70.12 in. |
| What is the curb weight, 2009 Volkswagen Jetta V 1.6 TDI (105 Hp)? | 1357 kg 2991.67 lbs. |
| What is the gross weight, 2009 Volkswagen Jetta V 1.6 TDI (105 Hp)? | 1940 kg 4276.97 lbs. |
| How much trunk (boot) space, 2009 Volkswagen Jetta Sedan? | 527 l 18.61 cu. ft. |
| How many gears, What type is the gearbox, 2009 Volkswagen Jetta V 1.6 TDI (105 Hp)? | 5, manual transmission |
