| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Passat |
| Generation | Passat Variant (B5) |
| Type (Engine) | 2.5 TDI (150 Hp) Syncro |
| Start of production | 1998 year |
| End of production | 2000 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 11.5 l/100 km 20.5 US mpg 24.6 UK mpg 8.7 km/l |
| Fuel consumption (economy) – extra urban | 6.3 l/100 km 37.3 US mpg 44.8 UK mpg 15.9 km/l |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 10.8 sec |
| Acceleration 0 – 62 mph | 10.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 10.3 sec |
| Maximum speed | 208 km/h 129.25 mph |
| Weight-to-power ratio | 10.1 kg/Hp, 98.7 Hp/tonne |
| Weight-to-torque ratio | 4.9 kg/Nm, 203.9 Nm/tonne |
| Engine specs | |
| Power | 150 Hp @ 4000 rpm. |
| Power per litre | 60.1 Hp/l |
| Torque | 310 Nm @ 1500 rpm. 228.64 lb.-ft. @ 1500 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | AFB, AKN |
| Engine displacement | 2496 cm3 152.32 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 78.3 mm 3.08 in. |
| Piston Stroke | 86.4 mm 3.4 in. |
| Compression ratio | 19.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.4 l 5.71 US qt | 4.75 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 10 l 10.57 US qt | 8.8 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1520 kg 3351.03 lbs. |
| Max. weight | 2070 kg 4563.57 lbs. |
| Max load | 550 kg 1212.54 lbs. |
| Trunk (boot) space – minimum | 495 l 17.48 cu. ft. |
| Trunk (boot) space – maximum | 1600 l 56.5 cu. ft. |
| Fuel tank capacity | 62 l 16.38 US gal | 13.64 UK gal |
| Dimensions | |
| Length | 4675 mm 184.06 in. |
| Width | 1740 mm 68.5 in. |
| Height | 1459 mm 57.44 in. |
| Wheelbase | 2703 mm 106.42 in. |
| Front track | 1498 mm 58.98 in. |
| Rear (Back) track | 1500 mm 59.06 in. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Coil spring |
| Rear suspension | Coil spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/55 R16 |
| Wheel rims size | 7J x 16 |
| What is the body type, Volkswagen Passat Variant (B5)? | Station wagon (estate), 5 Doors, 5 Seats |
|---|---|
| How fast is the car, 1998 Passat Variant (B5) 2.5 TDI (150 Hp) Syncro? | 208 km/h | 129.25 mph 0-100 km/h: 10.8 sec 0-60 mph: 10.3 sec |
| How much power, Volkswagen Passat Station wagon (estate) 1998 2.5 TDI (150 Hp) Syncro? | 150 Hp, 310 Nm 228.64 lb.-ft. |
| What is the engine size, Volkswagen Passat Station wagon (estate) 1998 2.5 TDI (150 Hp) Syncro? | 2.5 l 2496 cm3 152.32 cu. in. |
| How many cylinders, 1998 Volkswagen 2.5 TDI (150 Hp) Syncro? | 6, V-engine |
| What is the drivetrain, Volkswagen Passat Variant (B5) Station wagon (estate) 1998 2.5 TDI (150 Hp) Syncro? | All wheel drive (4×4). Internal Combustion engine. |
| How long is this vehicle, 1998 Volkswagen Passat Station wagon (estate)? | 4675 mm 184.06 in. |
| How wide is the vehicle, 1998 Volkswagen Passat Station wagon (estate)? | 1740 mm 68.5 in. |
| What is the curb weight, 1998 Volkswagen Passat Variant (B5) 2.5 TDI (150 Hp) Syncro? | 1520 kg 3351.03 lbs. |
| What is the gross weight, 1998 Volkswagen Passat Variant (B5) 2.5 TDI (150 Hp) Syncro? | 2070 kg 4563.57 lbs. |
| How much trunk (boot) space, 1998 Volkswagen Passat Station wagon (estate)? | 495 – 1600 l 17.48 – 56.5 cu. ft. |
| How many gears, What type is the gearbox, 1998 Volkswagen Passat Variant (B5) 2.5 TDI (150 Hp) Syncro? | 5, manual transmission |
