| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Polo |
| Generation | Polo V (5-door) |
| Type (Engine) | 1.6 TDI (90 Hp) DSG |
| Start of production | March, 2009 year |
| End of production | March, 2014 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 5.2 l/100 km 45.2 US mpg 54.3 UK mpg 19.2 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 3.7 l/100 km 63.6 US mpg 76.3 UK mpg 27 km/l |
| Fuel consumption (economy) – combined (NEDC) | 4.3 l/100 km 54.7 US mpg 65.7 UK mpg 23.3 km/l |
| CO2 emissions (NEDC) | 112 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 11.5 sec |
| Acceleration 0 – 62 mph | 11.5 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 10.9 sec |
| Maximum speed | 180 km/h 111.85 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 12.5 kg/Hp, 79.7 Hp/tonne |
| Weight-to-torque ratio | 4.9 kg/Nm, 203.7 Nm/tonne |
| Engine specs | |
| Power | 90 Hp @ 4200 rpm. |
| Power per litre | 56.3 Hp/l |
| Torque | 230 Nm @ 1500-2500 rpm. 169.64 lb.-ft. @ 1500-2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | EA189 / CAYB |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 79.5 mm 3.13 in. |
| Piston Stroke | 80.5 mm 3.17 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8 l 8.45 US qt | 7.04 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1129 kg 2489.02 lbs. |
| Max. weight | 1680 kg 3703.77 lbs. |
| Max load | 551 kg 1214.75 lbs. |
| Trunk (boot) space – minimum | 280 l 9.89 cu. ft. |
| Trunk (boot) space – maximum | 952 l 33.62 cu. ft. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (8%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 580 kg 1278.68 lbs. |
| Permitted towbar download | 50 kg 110.23 lbs. |
| Dimensions | |
| Length | 3970 mm 156.3 in. |
| Width | 1682 mm 66.22 in. |
| Width including mirrors | 1901 mm 74.84 in. |
| Height | 1462 mm 57.56 in. |
| Wheelbase | 2470 mm 97.24 in. |
| Front track | 1463 mm 57.6 in. |
| Rear (Back) track | 1456 mm 57.32 in. |
| Front overhang | 839 mm 33.03 in. |
| Rear overhang | 661 mm 26.02 in. |
| Ride height (ground clearance) | 153 mm 6.02 in. |
| Drag coefficient (Cd) | 0.32 |
| Minimum turning circle (turning diameter) | 10.6 m 34.78 ft. |
| Approach angle | 13.3° |
| Departure angle | 19.5° |
| Ramp-over (brakeover) angle | 11.1° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission DSG |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Coil spring, Torsion |
| Front brakes | Ventilated discs, 256×22 mm |
| Rear brakes | Disc, 232×9 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 185/60 R15; 195/55 R15; 215/45 R16; 215/40 R17 |
| Wheel rims size | 6J x 15; 7J x 16; 7J x 17 |
| What is the body type, Volkswagen Polo V (5-door)? | Hatchback, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Volkswagen Polo V (5-door) 1.6 TDI (90 Hp) DSG? | 4.3 l/100 km 54.7 US mpg 65.7 UK mpg 23.3 km/l |
| How ECO is the car, Volkswagen Polo 1.6 TDI (90 Hp) DSG? | 112 g/km CO2 Euro 5 |
| How fast is the car, 2009 Polo V (5-door) 1.6 TDI (90 Hp) DSG? | 180 km/h | 111.85 mph 0-100 km/h: 11.5 sec 0-60 mph: 10.9 sec |
| How much power, Volkswagen Polo Hatchback 2009 1.6 TDI (90 Hp) DSG? | 90 Hp, 230 Nm 169.64 lb.-ft. |
| What is the engine size, Volkswagen Polo Hatchback 2009 1.6 TDI (90 Hp) DSG? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2009 Volkswagen 1.6 TDI (90 Hp) DSG? | 4, Inline |
| What is the drivetrain, Volkswagen Polo V (5-door) Hatchback 2009 1.6 TDI (90 Hp) DSG? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2009 Volkswagen Polo Hatchback? | 3970 mm 156.3 in. |
| How wide is the vehicle, 2009 Volkswagen Polo Hatchback? | 1682 mm 66.22 in. |
| What is the curb weight, 2009 Volkswagen Polo V (5-door) 1.6 TDI (90 Hp) DSG? | 1129 kg 2489.02 lbs. |
| What is the gross weight, 2009 Volkswagen Polo V (5-door) 1.6 TDI (90 Hp) DSG? | 1680 kg 3703.77 lbs. |
| How much trunk (boot) space, 2009 Volkswagen Polo Hatchback? | 280 – 952 l 9.89 – 33.62 cu. ft. |
| How many gears, What type is the gearbox, 2009 Volkswagen Polo V (5-door) 1.6 TDI (90 Hp) DSG? | 7, automatic transmission DSG |
