| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Santana |
| Generation | Santana (32B) |
| Type (Engine) | 1.6 TD (70 Hp) |
| Start of production | August, 1982 year |
| End of production | December, 1984 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban | 7.1 l/100 km 33.1 US mpg 39.8 UK mpg 14.1 km/l |
| Fuel consumption (economy) – extra urban | 4.8 l/100 km 49 US mpg 58.9 UK mpg 20.8 km/l |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 16 sec |
| Acceleration 0 – 62 mph | 16 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 15.2 sec |
| Maximum speed | 152 km/h 94.45 mph |
| Weight-to-power ratio | 14.4 kg/Hp, 69.5 Hp/tonne |
| Weight-to-torque ratio | 7.6 kg/Nm, 132.1 Nm/tonne |
| Engine specs | |
| Power | 70 Hp @ 4500 rpm. |
| Power per litre | 44.1 Hp/l |
| Torque | 133 Nm @ 2600 rpm. 98.1 lb.-ft. @ 2600 rpm. |
| Engine layout | Front, Longitudinal |
| Engine displacement | 1588 cm3 96.91 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 76.5 mm 3.01 in. |
| Piston Stroke | 86.4 mm 3.4 in. |
| Compression ratio | 23:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Precombustion chamber injection |
| Engine aspiration | Turbocharger |
| Valvetrain | SOHC |
| Engine oil capacity | 3.5 l 3.7 US qt | 3.08 UK qt |
| Engine oil specification |  Log in to see. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1007 kg 2220.05 lbs. |
| Max. weight | 1460 kg 3218.75 lbs. |
| Max load | 453 kg 998.69 lbs. |
| Trunk (boot) space – minimum | 535 l 18.89 cu. ft. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (12%) | 1000 kg 2204.62 lbs. |
| Permitted trailer load without brakes | 500 kg 1102.31 lbs. |
| Dimensions | |
| Length | 4545 mm 178.94 in. |
| Width | 1695 mm 66.73 in. |
| Height | 1400 mm 55.12 in. |
| Wheelbase | 2550 mm 100.39 in. |
| Front track | 1400 mm 55.12 in. |
| Rear (Back) track | 1408 mm 55.43 in. |
| Minimum turning circle (turning diameter) | 10.7 m 35.1 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Trailing arm |
| Front brakes | Disc |
| Rear brakes | Drum |
| Steering type | Steering rack and pinion |
| Wheel rims size | 5.5J x 13 |
| What is the body type, Volkswagen Santana (32B)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| How fast is the car, 1982 Santana (32B) 1.6 TD (70 Hp)? | 152 km/h | 94.45 mph 0-100 km/h: 16 sec 0-60 mph: 15.2 sec |
| How much power, Volkswagen Santana Sedan 1982 1.6 TD (70 Hp)? | 70 Hp, 133 Nm 98.1 lb.-ft. |
| What is the engine size, Volkswagen Santana Sedan 1982 1.6 TD (70 Hp)? | 1.6 l 1588 cm3 96.91 cu. in. |
| How many cylinders, 1982 Volkswagen 1.6 TD (70 Hp)? | 4, Inline |
| What is the drivetrain, Volkswagen Santana (32B) Sedan 1982 1.6 TD (70 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 1982 Volkswagen Santana Sedan? | 4545 mm 178.94 in. |
| How wide is the vehicle, 1982 Volkswagen Santana Sedan? | 1695 mm 66.73 in. |
| What is the curb weight, 1982 Volkswagen Santana (32B) 1.6 TD (70 Hp)? | 1007 kg 2220.05 lbs. |
| What is the gross weight, 1982 Volkswagen Santana (32B) 1.6 TD (70 Hp)? | 1460 kg 3218.75 lbs. |
| How much trunk (boot) space, 1982 Volkswagen Santana Sedan? | 535 l 18.89 cu. ft. |
| How many gears, What type is the gearbox, 1982 Volkswagen Santana (32B) 1.6 TD (70 Hp)? | 4, manual transmission |
