| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Transporter |
| Generation | Transporter (T7) Panel Van |
| Type (Engine) | 2.0 TDI (110 Hp) L1H1 |
| Start of production | August, 2024 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Van |
| Seats | 2-3 |
| Doors | 4-5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 7.1 l/100 km 33.1 US mpg 39.8 UK mpg 14.1 km/l |
| CO2 emissions (WLTP) | 185 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 16.9 sec |
| Acceleration 0 – 62 mph | 16.9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 16.1 sec |
| Maximum speed | 155 km/h 96.31 mph |
| Emission standard | Euro 6e |
| Weight-to-power ratio | 16.3 kg/Hp, 61.2 Hp/tonne |
| Weight-to-torque ratio | 5.8 kg/Nm, 172.5 Nm/tonne |
| Engine specs | |
| Power | 110 Hp |
| Power per litre | 55.1 Hp/l |
| Torque | 310 Nm 228.64 lb.-ft. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Panther |
| Engine displacement | 1996 cm3 121.8 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 84.01 mm 3.31 in. |
| Piston Stroke | 90.03 mm 3.54 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1797 kg 3961.71 lbs. |
| Max. weight | 2800 kg 6172.94 lbs. |
| Max load | 1003 kg 2211.24 lbs. |
| Trunk (boot) space – maximum | 5800 l 204.83 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| AdBlue tank | 20 l 5.28 US gal | 4.4 UK gal |
| Max. roof load | 170 kg 374.79 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 5050 mm 198.82 in. |
| Width | 2032 mm 80 in. |
| Width including mirrors | 2275 mm 89.57 in. |
| Height | 1984 mm 78.11 in. |
| Wheelbase | 3100 mm 122.05 in. |
| Front overhang | 958 mm 37.72 in. |
| Rear overhang | 992 mm 39.06 in. |
| Minimum turning circle (turning diameter) | 12.5 m 41.01 ft. |
| Approach angle | 16.5° |
| Departure angle | 16.4° |
| Ramp-over (brakeover) angle | 13.1° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R16; 215/60 R17 |
| Wheel rims size | 6.5J x 16; 6.5J x 17 |
| What is the body type, Volkswagen Transporter (T7) Panel Van? | Van, 4-5 Doors, 2-3 Seats |
|---|---|
| What is the fuel economy, Volkswagen Transporter (T7) Panel Van 2.0 TDI (110 Hp) L1H1? | 7.1 l/100 km 33.1 US mpg 39.8 UK mpg 14.1 km/l |
| How ECO is the car, Volkswagen Transporter 2.0 TDI (110 Hp) L1H1? | 185 g/km CO2 Euro 6e |
| How fast is the car, 2024 Transporter (T7) Panel Van 2.0 TDI (110 Hp) L1H1? | 155 km/h | 96.31 mph 0-100 km/h: 16.9 sec 0-60 mph: 16.1 sec |
| How much power, Volkswagen Transporter Van 2024 2.0 TDI (110 Hp) L1H1? | 110 Hp, 310 Nm 228.64 lb.-ft. |
| What is the engine size, Volkswagen Transporter Van 2024 2.0 TDI (110 Hp) L1H1? | 2.0 l 1996 cm3 121.8 cu. in. |
| How many cylinders, 2024 Volkswagen 2.0 TDI (110 Hp) L1H1? | 4, Inline |
| What is the drivetrain, Volkswagen Transporter (T7) Panel Van Van 2024 2.0 TDI (110 Hp) L1H1? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2024 Volkswagen Transporter Van? | 5050 mm 198.82 in. |
| How wide is the vehicle, 2024 Volkswagen Transporter Van? | 2032 mm 80 in. |
| What is the curb weight, 2024 Volkswagen Transporter (T7) Panel Van 2.0 TDI (110 Hp) L1H1? | 1797 kg 3961.71 lbs. |
| What is the gross weight, 2024 Volkswagen Transporter (T7) Panel Van 2.0 TDI (110 Hp) L1H1? | 2800 kg 6172.94 lbs. |
| How much trunk (boot) space, 2024 Volkswagen Transporter Van? | 5800 l 204.83 cu. ft. |
| How many gears, What type is the gearbox, 2024 Volkswagen Transporter (T7) Panel Van 2.0 TDI (110 Hp) L1H1? | 6, manual transmission |
