| General information | |
|---|---|
| Brand | Volvo |
| Model | 66 |
| Generation | 66 Combi |
| Type (Engine) | DL 1.1 (47 Hp) Variornatic |
| Start of production | 1975 year |
| End of production | 1979 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Station wagon (estate) |
| Seats | 4 |
| Doors | 3 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 17.9 kg/Hp, 55.9 Hp/tonne |
| Weight-to-torque ratio | 11.2 kg/Nm, 89.2 Nm/tonne |
| Engine specs | |
| Power | 47 Hp @ 5000 rpm. |
| Power per litre | 42.4 Hp/l |
| Torque | 75 Nm @ 2700 rpm. 55.32 lb.-ft. @ 2700 rpm. |
| Engine Model/Code | B110E |
| Engine displacement | 1108 cm3 67.61 cu. in. |
| Number of cylinders | 4 |
| Cylinder Bore | 70 mm 2.76 in. |
| Piston Stroke | 72 mm 2.83 in. |
| Compression ratio | 8.5:1 |
| Engine aspiration | Naturally aspirated engine |
| Engine oil capacity | 3.3 l 3.49 US qt | 2.9 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 4.8 l 5.07 US qt | 4.22 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 841 kg 1854.09 lbs. |
| Max. weight | 1200 kg 2645.55 lbs. |
| Max load | 359 kg 791.46 lbs. |
| Fuel tank capacity | 42 l 11.1 US gal | 9.24 UK gal |
| Dimensions | |
| Length | 3900 mm 153.54 in. |
| Width | 1540 mm 60.63 in. |
| Height | 1380 mm 54.33 in. |
| Wheelbase | 2250 mm 88.58 in. |
| Front track | 1310 mm 51.57 in. |
| Rear (Back) track | 1240 mm 48.82 in. |
| Minimum turning circle (turning diameter) | 9.55 m 31.33 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | automatic transmission Variornatic |
| Rear suspension | Suspension De-Dion |
| Front brakes | Disc |
| Rear brakes | Drum |
| Wheel rims size | 4J x 14 |
| What is the body type, Volvo 66 Combi? | Station wagon (estate), 3 Doors, 4 Seats |
|---|---|
| How much power, Volvo 66 Station wagon (estate) 1975 DL 1.1 (47 Hp) Variornatic? | 47 Hp, 75 Nm 55.32 lb.-ft. |
| What is the engine size, Volvo 66 Station wagon (estate) 1975 DL 1.1 (47 Hp) Variornatic? | 1.1 l 1108 cm3 67.61 cu. in. |
| How many cylinders, 1975 Volvo DL 1.1 (47 Hp) Variornatic? | 4 |
| What is the drivetrain, Volvo 66 Combi Station wagon (estate) 1975 DL 1.1 (47 Hp) Variornatic? | Rear wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| How long is this vehicle, 1975 Volvo 66 Station wagon (estate)? | 3900 mm 153.54 in. |
| How wide is the vehicle, 1975 Volvo 66 Station wagon (estate)? | 1540 mm 60.63 in. |
| What is the curb weight, 1975 Volvo 66 Combi DL 1.1 (47 Hp) Variornatic? | 841 kg 1854.09 lbs. |
| What is the gross weight, 1975 Volvo 66 Combi DL 1.1 (47 Hp) Variornatic? | 1200 kg 2645.55 lbs. |
| How many gears, What type is the gearbox, 1975 Volvo 66 Combi DL 1.1 (47 Hp) Variornatic? | automatic transmission Variornatic |
