| General information | |
|---|---|
| Brand | Volvo |
| Model | S80 |
| Generation | S80 II (facelift 2009) |
| Type (Engine) | 2.4 D5 (205 Hp) |
| Start of production | 2009 year |
| End of production | 2011 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel consumption (economy) – urban (NEDC) | 8.7 l/100 km 27 US mpg 32.5 UK mpg 11.5 km/l |
| Fuel consumption (economy) – extra urban (NEDC) | 4.8 l/100 km 49 US mpg 58.9 UK mpg 20.8 km/l |
| Fuel consumption (economy) – combined (NEDC) | 6.2 l/100 km 37.9 US mpg 45.6 UK mpg 16.1 km/l |
| CO2 emissions (NEDC) | 164 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 8 sec |
| Acceleration 0 – 62 mph | 8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.6 sec |
| Maximum speed | 230 km/h 142.92 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 7.6 kg/Hp, 132.4 Hp/tonne |
| Weight-to-torque ratio | 3.7 kg/Nm, 271.3 Nm/tonne |
| Engine specs | |
| Power | 205 Hp @ 4000 rpm. |
| Power per litre | 85.4 Hp/l |
| Torque | 420 Nm @ 1500-3250 rpm. 309.78 lb.-ft. @ 1500-3250 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | D5244T10 |
| Engine displacement | 2400 cm3 146.46 cu. in. |
| Number of cylinders | 5 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 93.15 mm 3.67 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 6 l 6.34 US qt | 5.28 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 12.6 l 13.31 US qt | 11.09 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1548 kg 3412.76 lbs. |
| Max. weight | 2190 kg 4828.12 lbs. |
| Max load | 642 kg 1415.37 lbs. |
| Trunk (boot) space – minimum | 480 l 16.95 cu. ft. |
| Fuel tank capacity | 70 l 18.49 US gal | 15.4 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 1600 kg 3527.4 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4851 mm 190.98 in. |
| Width | 1861 mm 73.27 in. |
| Width including mirrors | 2106 mm 82.91 in. |
| Height | 1493 mm 58.78 in. |
| Wheelbase | 2835 mm 111.61 in. |
| Front track | 1588 mm 62.52 in. |
| Rear (Back) track | 1585 mm 62.4 in. |
| Front overhang | 978 mm 38.5 in. |
| Rear overhang | 1038 mm 40.87 in. |
| Minimum turning circle (turning diameter) | 11.7 m 38.39 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/55 R16; 245/40 R18 |
| Wheel rims size | 7J x 16; 8J x 18 |
| What is the body type, Volvo S80 II (facelift 2009)? | Sedan, 4 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Volvo S80 II (facelift 2009) 2.4 D5 (205 Hp)? | 6.2 l/100 km 37.9 US mpg 45.6 UK mpg 16.1 km/l |
| How ECO is the car, Volvo S80 2.4 D5 (205 Hp)? | 164 g/km CO2 Euro 5 |
| How fast is the car, 2009 S80 II (facelift 2009) 2.4 D5 (205 Hp)? | 230 km/h | 142.92 mph 0-100 km/h: 8 sec 0-60 mph: 7.6 sec |
| How much power, Volvo S80 Sedan 2009 2.4 D5 (205 Hp)? | 205 Hp, 420 Nm 309.78 lb.-ft. |
| What is the engine size, Volvo S80 Sedan 2009 2.4 D5 (205 Hp)? | 2.4 l 2400 cm3 146.46 cu. in. |
| How many cylinders, 2009 Volvo 2.4 D5 (205 Hp)? | 5, Inline |
| What is the drivetrain, Volvo S80 II (facelift 2009) Sedan 2009 2.4 D5 (205 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2009 Volvo S80 Sedan? | 4851 mm 190.98 in. |
| How wide is the vehicle, 2009 Volvo S80 Sedan? | 1861 mm 73.27 in. |
| What is the curb weight, 2009 Volvo S80 II (facelift 2009) 2.4 D5 (205 Hp)? | 1548 kg 3412.76 lbs. |
| What is the gross weight, 2009 Volvo S80 II (facelift 2009) 2.4 D5 (205 Hp)? | 2190 kg 4828.12 lbs. |
| How much trunk (boot) space, 2009 Volvo S80 Sedan? | 480 l 16.95 cu. ft. |
| How many gears, What type is the gearbox, 2009 Volvo S80 II (facelift 2009) 2.4 D5 (205 Hp)? | 6, manual transmission |
