| General information | |
|---|---|
| Brand | Weltmeister |
| Model | EX5 |
| Generation | EX5 |
| Type (Engine) | 52.7 kWh (218 Hp) Electric |
| Start of production | April, 2018 year |
| End of production | 2022 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | SUV, Crossover |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Weight-to-power ratio | 8.1 kg/Hp, 123.8 Hp/tonne |
| Weight-to-torque ratio | 5.6 kg/Nm, 178.9 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 52.7 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery location | Below the floor |
| All-electric range | 403 km 250.41 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 218 Hp |
| Electric motor Torque | 315 Nm
232.33 lb.-ft. |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| System power | 218 Hp |
| System torque | 315 Nm 232.33 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1761 kg 3882.34 lbs. |
| Dimensions | |
| Length | 4585 mm 180.51 in. |
| Width | 1835 mm 72.24 in. |
| Height | 1672 mm 65.83 in. |
| Wheelbase | 2703 mm 106.42 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Torsion |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/60 R17; 225/55 R18 |
| Wheel rims size | 17; 18 |
| What is the body type, Weltmeister EX5? | SUV, Crossover, 5 Doors, 5 Seats |
|---|---|
| What is the range of pure electric driving, 52.7 kWh (218 Hp) Electric? | 403 km 250.41 mi |
| How much power, Weltmeister EX5 SUV, Crossover 2018 52.7 kWh (218 Hp) Electric? | 218 Hp, 315 Nm 232.33 lb.-ft. |
| What is the drivetrain, Weltmeister EX5 SUV, Crossover 2018 52.7 kWh (218 Hp) Electric? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2018 Weltmeister EX5 SUV, Crossover? | 4585 mm 180.51 in. |
| How wide is the vehicle, 2018 Weltmeister EX5 SUV, Crossover? | 1835 mm 72.24 in. |
| What is the curb weight, 2018 Weltmeister EX5 52.7 kWh (218 Hp) Electric? | 1761 kg 3882.34 lbs. |
| How many gears, What type is the gearbox, 2018 Weltmeister EX5 52.7 kWh (218 Hp) Electric? | 1, automatic transmission |
