| General information | |
|---|---|
| Brand | Zeekr |
| Model | 009 |
| Generation | 009 |
| Type (Engine) | 116 kWh (340 Hp) Single Motor FWD Electric |
| Start of production | June, 2024 year |
| Powertrain Architecture | BEV (Electric Vehicle) |
| Body type | Minivan |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Electricity |
| Acceleration 0 – 100 km/h | 7.9 sec |
| Acceleration 0 – 62 mph | 7.9 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.5 sec |
| Maximum speed | 210 km/h 130.49 mph |
| Weight-to-power ratio | 8.1 kg/Hp, 122.7 Hp/tonne |
| Weight-to-torque ratio | 7.4 kg/Nm, 134.7 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 116 kWh |
| Battery voltage | 400 V |
| Battery technology | Lithium nickel manganese cobalt oxides (Li-NMC) |
| Battery location | Below the floor |
| All-electric range (WLTP) | 604 km 375.31 mi |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 340 Hp |
| Electric motor Torque | 373 Nm
275.11 lb.-ft. |
| Electric motor location | Front axle, Transverse |
| Electric motor type | Synchronous |
| System power | 340 Hp |
| System torque | 373 Nm 275.11 lb.-ft. |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2770 kg 6106.8 lbs. |
| Trunk (boot) space – minimum | 574 l 20.27 cu. ft. |
| Trunk (boot) space – maximum | 2979 l 105.2 cu. ft. |
| Dimensions | |
| Length | 5209 mm 205.08 in. |
| Width | 2024 mm 79.69 in. |
| Height | 1812 mm 71.34 in. |
| Wheelbase | 3205 mm 126.18 in. |
| Front track | 1702 mm 67.01 in. |
| Rear (Back) track | 1714 mm 67.48 in. |
| Ride height (ground clearance) | 142 mm 5.59 in. |
| Minimum turning circle (turning diameter) | 12.4 m 40.68 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | One electric motor drives the front wheels. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 1 gears, automatic transmission |
| Front suspension | Double wishbone, Transverse stabilizer |
| Rear suspension | Independent multi-link suspension, Transverse stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/50 R19 |
| Wheel rims size | 19 |
| What is the body type, Zeekr 009? | Minivan, 5 Doors, 7 Seats |
|---|---|
| What is the range of pure electric driving, 116 kWh (340 Hp) Single Motor FWD Electric? | 604 km 375.31 mi |
| How fast is the car, 2024 009 116 kWh (340 Hp) Single Motor FWD Electric? | 210 km/h | 130.49 mph 0-100 km/h: 7.9 sec 0-60 mph: 7.5 sec |
| How much power, Zeekr 009 Minivan 2024 116 kWh (340 Hp) Single Motor FWD Electric? | 340 Hp, 373 Nm 275.11 lb.-ft. |
| What is the drivetrain, Zeekr 009 Minivan 2024 116 kWh (340 Hp) Single Motor FWD Electric? | Front wheel drive. BEV (Electric Vehicle). One electric motor drives the front wheels. |
| How long is this vehicle, 2024 Zeekr 009 Minivan? | 5209 mm 205.08 in. |
| How wide is the vehicle, 2024 Zeekr 009 Minivan? | 2024 mm 79.69 in. |
| What is the curb weight, 2024 Zeekr 009 116 kWh (340 Hp) Single Motor FWD Electric? | 2770 kg 6106.8 lbs. |
| How much trunk (boot) space, 2024 Zeekr 009 Minivan? | 574 – 2979 l 20.27 – 105.2 cu. ft. |
| How many gears, What type is the gearbox, 2024 Zeekr 009 116 kWh (340 Hp) Single Motor FWD Electric? | 1, automatic transmission |
